Operating and Monitoring Systems
R. STAHL's explosion-protected Human Machine Interfaces are the window to production processes in Zone 1, 2, 21 and 22. R. STAHL's operator stations for process automation have been designed for the chemical, pharmaceutical and life sciences industries. In contrast, the operator interfaces for harsh, extreme environments have been designed for all kinds of outdoor areas and for operation on offshore rigs. Panel-mount devices include all HMIs without enclosure, designed for integration into machines / pharma walls, and peripheral devices include our accessories such as RFID and barcode readers For any specific requirements, please refer to our HMI finder.
ORCA Panel PCs / Thin Clients Operator Stations
Technology: Panel PCs / Thin Clients
Application range (zones): 2, 22
Application range (divisions): Class II, Division 1 and 2, Class III, Class I, Zone 2 / Division 2
Power supply: 24 VDC or 230 VAC
Ethernet / Data: E-Box Standard: 10/100/1000Base-TX, E-Box Pro:, 2x 10/100/1000Base-TX oder, 1x 10/100/1000Base-TX + 2x 1000Base-SX oder, 1x 10/100/1000Base-TX + 2x 1000Base-LX
Interface medium: LX: single mode optical cable, SX: multi-mode optical cable, TX: min. CAT5 Data transmission
Display size inch: 22
Temperature range: -20 °C … +50 °C
Enclosure type: ORCA OS enclosure
Enclosure material: Stainless steel enclosure V2A or V4A
Keyboard: optional, 105 keys with trackball / joystick / touchpad
Application range (zones): 2, 22
Application range (divisions): Class II, Division 1 and 2, Class III, Class I, Zone 2 / Division 2
Power supply: 24 VDC or 230 VAC
Ethernet / Data: E-Box Standard: 10/100/1000Base-TX, E-Box Pro:, 2x 10/100/1000Base-TX oder, 1x 10/100/1000Base-TX + 2x 1000Base-SX oder, 1x 10/100/1000Base-TX + 2x 1000Base-LX
Interface medium: LX: single mode optical cable, SX: multi-mode optical cable, TX: min. CAT5 Data transmission
Display size inch: 22
Temperature range: -20 °C … +50 °C
Enclosure type: ORCA OS enclosure
Enclosure material: Stainless steel enclosure V2A or V4A
Keyboard: optional, 105 keys with trackball / joystick / touchpad
